Swedbank Pay’s API Platform is built using the REST architectural style and the request and responses come in the JSON format. The API has predictable, resource-oriented URIs and use default HTTP features, like HTTP authentication (using OAuth 2), HTTP methods and headers. These techniques are widely used and understood by most HTTP client libraries.

Connection and Protocol

All requests towards Swedbank Pay API Platform are made with HTTP/1.1 over a secure a TLS 1.2 (or higher) connection. Older HTTP clients running on older operating systems and frameworks might receive connection errors when connecting to Swedbank Pay’s APIs. This is most likely due to the connection being made from the client with TLS 1.0 or even SSL, which are all insecure and deprecated. If such is the case, ensure that you are able to connect over a TLS 1.2 connection by reading information regarding your programming languages and environments (Java, PHP Curl, PHP Zend, Ruby, Python, Node.js Request).

You can inspect Swedbank Pay’s TLS and cipher suite support at SSL Labs. Support for HTTP/2 in our APIs is being investigated.

Headers

All requests against the API Platform should have a few common headers:

HTTP request

POST /some/resource HTTP/1.1
Content-Type: application/json; charset=utf-8
Accept: application/problem+json; q=1.0, application/json; q=0.9
Authorization: "Bearer 123456781234123412341234567890AB"
Session-Id: 779da454399742248f2942bb064c4707
Forwarded: for=82.115.151.177; host=example.com; proto=https
Required Header Description
✔︎ Content-Type The content type of the body of the HTTP request. Usually set to application/json.
✔︎ Accept The content type accepted by the client. Usually set to application/json and application/problem+json so both regular responses as well as errors can be received properly.
✔︎ Authorization The OAuth 2 Access Token is generated in Swedbank Pay Admin. See the admin guide on how to get started.
  Session-Id A trace identifier used to trace calls through the API Platform (ref RFC 7329). Each request must mint a new GUID/UUID. If no Session-Id is provided, Swedbank Pay will generate one for the request.
  Forwarded The IP address of the consumer as well as the host and protocol of the consumer-facing web page. When the header is present, only the for parameter containing the consumer IP address is required, the other parameters are optional. See RFC 7239 for details.

URI Usage

The base URIs of the API Platform are:

Environment Base URL
Test https://api.externalintegration.payex.com/
Production https://api.payex.com/

An important part of REST is its use of hypermedia. Instead of having to perform complex state management and hard coding URIs and the availability of different operations in the client, this task is moved to the server. The client simply follows links and performs operations provided by the API, given the current state of the resource. The server controls the state and lets the client know through hypermedia what’s possible in the current state of the resource. To get an introduction to hypermedia, please watch this 20 minute video.

warning

Don’t build URIs

It is very important that only the base URIs of Swedbank Pay’s APIs are stored in your system. All other URIs are returned dynamically in the response. Swedbank Pay cannot guarantee that your implementation will remain working if you store any other URIs in your system. When performing requests, please make sure to use the complete URIs that are returned in the response. Do not attempt to parse or build upon the returned data – you should not put any special significance to the information you might glean from an URI. URIs should be treated as opaque identifiers you can use to retrieve the identified resource – nothing more, nothing less. If you don’t follow this advice, your integration most assuredly will break when Swedbank Pay makes updates in the future.

Uniform Responses

When a POST or PATCH request is performed, the whole target resource representation is returned in the response, as when performing a GET request on the resource URI. This is an economic approach that limits the number of necessary GET requests.

Expansion

The payment resource contain the ID of related sub-resources in its response properties. These sub-resources can be expanded inline by using the request parameter expand. This is an effective way to limit the number of necessary calls to the API, as you return several properties related to a Payment resource in a single request.

Note that the expand parameter is available to all API requests but only applies to the request response. This means that you can use the expand parameter on a POST or PATCHrequest to get a response containing the target resource including expanded properties.

This example below add the urls and authorizations property inlines to the response, enabling you to access information from these sub-resources.

HTTP request with expansion

GET /psp/creditcard/payments/7e6cdfc3-1276-44e9-9992-7cf4419750e1?$expand=urls,authorizations HTTP/1.1
Host: api.externalintegration.payex.com

To avoid unnecessary overhead, you should only expand the nodes you need info about.

Data Types

Some datatypes, like currency, dates and amounts, are managed in a coherent manner across the entire API Platform.

Currency

All currencies are expressed according to the ISO 4217 standard, e.g SEK, EUR, NOK.

Dates

All dates are expressed according to the ISO 8601 standard that combine dates, time and timezone data into a string, e.g. 2018-09-14T13:21:57.6627579Z.

Locale

When defining locale, we use the combination of language (ISO 639-1) and country codes (ISO 3166), e.g. nb-NO, sv-SE, en-US.

Monetary Amounts

All monetary amounts are entered in the lowest momentary units of the selected currency. The amount of SEK and NOK are in ören/ører, and EUR is in cents. Another way to put it is that the code amount is expressed as if the true amount is multiplied by 100.

True amount Code amount
NOK 100.00 10000
SEK 50.00 5000
€ 10.00 1000

Operations

When a resource is created and during its lifetime, it will have a set of operations that can be performed on it. Which operations that are available in a given state varies depending on payment instrument used, what the access token is authorized to do, etc. A subset of possible operations are described below. Visit the technical reference page of a payment instrument for instrument specific operations.

JSON with Operations

{
    "payment": {},
    "operations": [
        {
            "href": "http://api.externalintegration.payex.com/psp/creditcard/payments/7e6cdfc3-1276-44e9-9992-7cf4419750e1",
            "rel": "update-payment-abort",
            "method": "PATCH"
        },
        {
            "href": "https://ecom.externalintegration.payex.com/creditcard/payments/authorize/afccf3d0016340620756d5ff3e08f69b555fbe2e45ca71f4bd159ebdb0f00065",
            "rel": "redirect-authorization",
            "method": "GET"
        },
        {
            "href": "https://ecom.externalintegration.payex.com/swish/core/scripts/client/px.swish.client.js?token=afccf3d0016340620756d5ff3e08f69b555fbe2e45ca71f4bd159ebdb0f00065",
            "rel": "view-payment",
            "method": "GET",
            "contentType": "application/javascript"
        },
        {
            "href": "https://api.externalintegration.payex.com/psp/creditcard/payments/7e6cdfc3-1276-44e9-9992-7cf4419750e1/captures",
            "rel": "create-capture",
            "method": "POST"
        }
    ]
}
Property Description
href The target URI to perform the operation against.
rel The name of the relation the operation has to the current resource.
method The HTTP method to use when performing the operation.

The operations should be performed as described in each response and not as described here in the documentation. Always use the href and method as specified in the response by finding the appropriate operation based on its rel value.

PayeeReference

The payeeReference given when creating transactions and payments has some specific processing rules depending on specifications in the contract.

  • It must be unique for every operation, used to ensure exactly-once delivery of a transactional operation from the merchant system.
  • Its length and content validation is dependent on whether the transaction.number or the payeeReference is sent to the acquirer.
    1. If you select Option A in the settlement process (Swedbank Pay will handle the settlement), Swedbank Pay will send the transaction.number to the acquirer and the payeeReference may have the format of string(30).
    2. If you select Option B in the settlement process (you will handle the settlement yourself), Swedbank Pay will send the payeeReference to the acquirer and it will be limited to the format of string(12) and all characters must be digits.

Read more about the settlement process here.

Callback

When a change or update from the back-end system are made on a payment or transaction, Swedbank Pay will perform a callback to inform the payee (merchant) about this update.

  • Setting a callbackUrl in the HTTP POST API is optional, but highly recommended. If a payer closes the browser window, a network error or something else happens that prevents the payer from being redirect from Swedbank Pay back to the merchant website, the callback is what ensures that you receive information about what happened with the payment.
  • When a change or update from the back-end system are made on a payment or transaction, Swedbank Pay will perform an asynchronous server-to-server callback to inform the payee (merchant) about this update.
  • Swedbank Pay will make an HTTP POST to the callbackUrl that was specified when the payee (merchant) created the payment.
  • When the callbackUrl receives such a callback, an HTTP GET request must be made on the payment or on the transaction. The retrieved payment or transaction resource will give you the necessary information about the recent change/update.
  • The callback will be retried if it fails. Below are the retry timings, in seconds from the initial transaction time:
    • 30 seconds
    • 60 seconds
    • 360 seconds
    • 432 seconds
    • 864 seconds
    • 1265 seconds
  • The callback is sent from the following IP address: 82.115.146.1
  • A callback should return a 200 OK response.

Payment Instrument Callback

{
    "payment": {
        "id": "/psp/creditcard/payments/7e6cdfc3-1276-44e9-9992-7cf4419750e1",
        "number": 222222222
    },
    "transaction": {
        "id": "/psp/creditcard/payments/7e6cdfc3-1276-44e9-9992-7cf4419750e1/<transaction type>/ec2a9b09-601a-42ae-8e33-a5737e1cf177",
        "number": 333333333
    }
}
Parameter Description
<transaction type> authorizations, captures, cancellations, reversals

The sequence diagram below shows the HTTP POST you will receive from Swedbank Pay, and the two GET requests that you make to get the updated status.

sequenceDiagram
    Participant Merchant
    Participant SwedbankPay as Swedbank Pay

    activate SwedbankPay
    SwedbankPay->>+Merchant: POST <callbackUrl>
    deactivate SwedbankPay
    note left of Merchant: Callback by Swedbank Pay
    Merchant-->>+SwedbankPay: HTTP response
    Merchant->>+SwedbankPay: GET creditcard payment
    deactivate Merchant
    note left of Merchant: First API request
    SwedbankPay-->>+Merchant: payment resource
    deactivate SwedbankPay

Problems

When performing operations against the API, it will respond with a problem message that contain details of the error type if the request could not be successfully performed. Regardless of why the error occurred, the problem message will follow the same structure as specified in the Problem Details for HTTP APIs (RFC 7807) specification.

The structure of a problem message will look like this:

Problem Example

{
    "type": "https://api.payex.com/psp/errordetail/creditcard/inputerror",
    "title": "There was an input error",
    "detail": "Please correct the errors and retry the request",
    "instance": "ec2a9b09-601a-42ae-8e33-a5737e1cf177",
    "status": 400,
    "action": "RetryNewData",
    "problems": [{
        "name": "CreditCardParameters.Issuer",
        "description": "minimum one issuer must be enabled"
    }]
}
Property Type Description
type string The URI that identifies the error type. This is the only property usable for programmatic identification of the type of error! When dereferenced, it might lead you to a human readable description of the error and how it can be recovered from.
title string The title contains a human readable description of the error.
detail string A detailed, human readable description of the error and how you can recover from it.
instance string The identifier of the error instance. This might be of use to Swedbank Pay support personnel in order to find the exact error and the context it occurred in.
status integer The HTTP status code that the problem was served with.
action string The action indicates how the error can be recovered from.
problems array The array of problem detail objects.
└➔ name string The name of the property, header, object, entity or likewise that was erroneous.
└➔ description string The human readable description of what was wrong with the property, header, object, entity or likewise identified by name.

Common Problems

All common problem types will have a URI in the format https://api.payex.com/psp/errordetail/<payment-instrument>/<error-type>. The URI is an identifier that you can hard-code and implement logic around. It is currently not not possible to dereference this URI, although that might be possible in the future.

Type Status Description
inputerror 400 The server cannot or will not process the request due to an apparent client error (e.g. malformed request syntax, size to large, invalid request).
forbidden 403 The request was valid, but the server is refusing the action. The necessary permissions to access the resource might be lacking.
notfound 404 The requested resource could not be found, but may be available in the future. Subsequent requests are permissible.
systemerror 500 A generic error message.
configurationerror 500 A error relating to configuration issues.

Payment Instrument Specific Problems

Problem types for a specific payment instrument will have a URI in the format https://api.payex.com/psp/errordetail/<payment-instrument>/<error-type>. You can read more about the payment instrument specific problem messages below:
